REPT Battero BESS GMS Solar

REPT

REPT BATTERO
Powering the Future with Advanced Battery Energy Storage Systems


Outdoor Liquid Cooling Cabinet

Battery Cell 280 Ah

Cycling Life 8,000

Liquid Cooling Container

Cycle Life 8,000-10,000

BESS Container 20 fts with Liquid Cooling

Project Reference

REPT BESS GMS Solar
REPT BESS GMS Solar
REPT BESS GMS Solar
REPT BESS GMS Solar
REPT BESS GMS Solar
REPT BESS GMS Solar

Global Presence and Capacity

REPT BESS GMS Solar

China

206 GWh

capacity across multiple locations
(Wenzhou, Liuzhou, Foshan, Chongqing)

Indonesia

50 GWh

planned capacity

Morocco

40 GWh

planned capacity

Europe

40 GWh

planned capacity

North America

Under investigation for future expansion

By 2030, we aim to achieve a total production capacity exceeding 300GWh.

Technical

BATTERY CELL Catalogue

GMS Solar REPT BESS Cell Battery 205Ah

205Ah

GMS Solar REPT BESS Cell Battery 280Ah

280Ah

GMS Solar REPT BESS Cell Battery 320Ah

320Ah

GMS Solar REPT BESS Cell Battery 345Ah

345Ah

Download Datasheet

Battery Cell

INTERNAL CIRCULATION SELF-BALANCING TECHNOLOGY

By using special additives in the battery, the POWER OF DIIFERENT CELLS can be flexibly adjusted during the charging process, so as to improve the consistency of power

WENDING EXCLUSIVE INNOVATION TECHNOLOGY

Adopt the ceiling cover design and fully fixed integrated ceiling structure Effectively improve the space utilization rate by more than 7%

HIGH SAFETY : NO U-BEND

More Stable & High Safety in Life Cycle

Traditional Battery

REPT WENDING CELL

LIQUID COOLED

FULLY PARALLEL design

REPT PARALLEL Liquid-Cooled

Better Cell SOC, Less Power Consumption, Longer Life

PARALLELL Liquid-Cooled : REPT

SERIES-Liquid-Cooled Pack in the Market

Parallel Coolant to ensure uniform Internal Flow

Proven by Thermal Testing Result

Maximum Temperature

36.2

Maximum Temperature Difference

2.8

Average Temperature (Coolant at the Inlet)

20.1

Average Temperature (Coolant at the Outlet)

22.1

Module

Battery Pack (Module) : AEROSOL in the module

104
Each Module contain

Battery Cells

2
Each Module contain

Hot Aerosol

while in the market do not have Aerosol in the module

NO

LEAK

Helium Leakage Detection

FIRE

Suppression

at the module level, more Safety

IP67

Modules Level

No water vapor enters into the module while module in the market is IP65

COOLANT

Distributor

Coolant is retained in the distributor and do not flow into the module

FAST

Plug & Play

Coupling Avoid Liquid Leakage , Convenient for Maintenance and module replacement

INSULATION

Cotton

at the bottom of the module

Suppression

Technology Innovation

Fire Suppression System Configuration

Aerosol cylinder layout

Water pipe Layout

Ventilation(NFPA69)

Explosion Proof Prevention

Large Scale Fire Test

1

batteries Module

Heating cells in multiple locations at the same time in battery module.

2

batteries Module

Evaluate how many cells need to be thermal runaway, then fire break out.

1

With batteries

Use the same method at rack level, making several racks thermal runaway.

2

With batteries

Use the same method at rack level, making several racks thermal runaway.

1

With batteries

Use the same method at rack level, making several racks thermal runaway.

2

With batteries

Ensure that the fire spreads throughout the whole DC block.

3

Record the temperature on the surface of adjacent containers.
(<cell venting temperature)

4

Record the heat flux on the surface of adjacent containers.

Three Helium Detection test at Module Level

Container

Leakage Detection at Module Level

  • If leakage occurs, the return pressure is lower than 0.4 bar, system low pressure alarm reported, the refill tank will pump coolant into the system, when the return pressure is higher than 0.4 bar, alarm eliminated
  • When there is no more coolant in the refill tank, resulting in the return water pressure has been lower than 0.4 bar, it will report low pressure alarm and low liquid level alarm.
  • 15 meters of flood line, wired at the bottom of the container, to detect any liquid leaks inside the container (Coolant distributor, Pipelines, Openings). See the red line in the left picture.
  • Each container is equipped with 9 one-way floor drains. Liquid can leak out of the container, but will not enter from the outside, so water will not accumulate inside the container.

Multi-Level Short-Circuit Protection

  • 5 Protections in various electrical locations
  • Fuses in various electrical locations

Certificate

Rigorous Testing and Certification

BESS
BESS

Our commitment to quality and safety is evident in our extensive testing procedures:

  • High temperature and humidity cycling tests
  • Helium leak detection at multiple stages
  • Large-scale fire tests scheduled for comprehensive safety evaluation

Our systems meet or exceed international standards, including UL 9540, UL9540A, UL1973, IEC 62619, IEC 63056, IEC61000, IEC 62477, UN 38.3, NFPA68, and NFPA69.

Integrated Supply Chain

REPT BATTERO's strength lies in our vertically integrated supply chain, spanning from raw material extraction to end-product manufacturing:

Lithium

: Sourced from Argentina and Zimbabwe

Nickel and Cobalt

: Produced in Indonesia

Cathode and Anode Materials

: Manufactured in China and Indonesia

Separator and Electrolyte

: Produced in various global locations

Cell, Module, and Pack Production

: State-of-the-art facilities across multiple countries

This comprehensive supply chain management ensures quality control, cost-effectiveness, and reliability at every stage of production.

Cutting-Edge DC Block Technology

REPT BATTERO is pioneering BESS innovation with our state-of-the-art DC Block technology. Our development roadmap showcases our clear vision for the future of energy storage:

DC Block Evolution:

Current Flagship Models:

1

5.1MWh DC Block

- 320Ah Wending® Cell

- 1P416S configuration

- Rated DC voltage: 1,331.2V

- Dimensions: 6058L×2438W×2896H (20HQ ISO container)

2

5.5MWh DC Block

- 345Ah Wending® Cell

- 1P416S configuration

- Rated DC voltage: 1,331.2V

- Dimensions: 6058L×2438W×2896H (20HQ ISO container)

Both models feature advanced liquid cooling systems and comply with stringent industry standards including UL 9540, UL9540A, IEC 62619, and NFPA68/69.

Advanced Design and Efficiency

Our latest DC Block design offers significant improvements over previous generations:

Innovative Y104 Module

At the heart of our DC Block systems is the Y104 module:

Thermal Management Excellence

REPT’s liquid cooling system sets new industry standards:

Unparalleled Safety Features

BESS REPT GMS Solar

About rept

REPT BATTERO, a subsidiary of the Fortune 500 Global company Tsingshan Group, stands at the forefront of the energy storage revolution. As a key player in the global lithium-ion battery supply chain, we combine cutting-edge technology with a fully integrated supply chain to deliver world-class Battery Energy Storage Systems (BESS).

Tsingshan - Parent Company

Our parent company, Tsingshan Group, is a global leader in nickel and stainless steel production, providing us with unparalleled access to critical raw materials and manufacturing expertise.

BESS REPT GMS Solar

Customer Portfolio

Our BESS solutions have been adopted by leading companies worldwide:

– North America: Powin, ESS Inc., Honeywell

– Asia: Sungrow, Envision, Jinko



Our diverse customer base demonstrates the versatility and reliability of our energy storage solutions across various applications and markets.

Future-Ready Energy Storage

REPT BATTERO’s DC Block technology represents the pinnacle of BESS innovation. With our continuous improvement roadmap and commitment to safety and efficiency, we’re not just meeting the energy storage needs of today – we’re shaping the power systems of tomorrow.

Choose REPT BATTERO for unmatched performance, reliability, and peace of mind in your energy storage solutions.

Next Coming Year

THE ART OF MATRIX

CHARGE TO CELL, FUTURE TO EXCEL

REPT New Container of 7 MWh

BESS REPT GMS Solar
BESS REPT GMS Solar

7.03MWh

Installed Energy

Large Cell

500Ah+

Land Investment Save

25%

Area Energy Density Increase by

40%

Transposition Layout Loading Enhancement

Zero Degradation High Efficiency

REPT New Battery cell product

GMS Solar REPT BESS Cell Battery 587Ah
Ultra-large Capacity

587Ah

Ultra-high Efficiency

96.4%

Ultra-high Energy Density

430Wh/L

Super Durability

25-30 Years

Zero Degradation for 5 Years

12,000 Cycle+Life
